Universities and machine code

  • Thread starter Deleted member 53988
  • Start date

connchri

Member

Reaction score: 4
Messages: 28

Maelstorm,

In some other universities there are even binary coding lessons?
I can't comment from a Computer Science course POV. But I can say that, where I did my undergrad, we had a few lessons in Assembly. I've still got the old book for the x86. I bought this second hand in 2008. The unltimate aim, however, was to familiarise ourselves, along with C++, for when we went on to program Programmable Logic Controllers, debugging C code, accessing registers that represent hardware inputs/outputs, etc. It's not something I've looked at in great detail since, but if they offered this in an Electronic and Electrical engineering course, I would hazard a guess that it would be covered in greater detail, including byte code, in a Computer Science Degree.


Attachments

OP
OP
D

Deleted member 53988

Guest


Please make up your mind if you mean binary or assembly.
Crivens,

I meant binary coding.

I wrote:

In some other universities there are even binary coding lessons?

EDIT: Machine code is binary code, hexadecimal code, octal code...


Crivens

Moderator
Staff member
Moderator

Reaction score: 887
Messages: 1,841

I remember being able to read Z80 code in hex dumps, and a friend of mine wrote 6502 code directly as hex code. That is where you might start. Modern cpus have too many instructions, sometimes more than the base word count for school children... no way you read that fluently in a year. No courses will be there for that level. There are plenty of 8 bit computers around to train with, and it will be fun.

OP
OP
D

Deleted member 53988

Guest


Terminology, this is not the same. Machine code is binary, not all binary is machine code. Hence the 'illegal instruction trap'.
Crivens,

You say that machine code is binary and at the same time say that not all binary is machine code.

This is a contradiction.


ralphbsz

Daemon

Reaction score: 1,123
Messages: 1,782

I've been writing software professionally for ~25 years now. Typically in groups of anywhere from 5 to 300 people.

I've seen about 0.1 cases where we actually coded in binary (meaning we wrote instructions that the CPU executed, and we didn't use assembly but emitted the numeric instructions). That was a project where the only way to get the required speed (image processing on an i386, which lacked sufficient registers) was to generate a routine on the fly and execute it, and stuff the constants and pointer offsets into the instruction stream. And even this was not done by actually coding whole instructions sequences in binary. Instead we wrote sample code in C++, compiled it with assembly listing, then ran the assembly listing through awk to generate a version of the executable code that could be copied into a second C++ program as an array of integer constants (bytes that were the instructions), the modified that array programmatically, and executed it.

I've never heard of a case where the assembler is incapable of generating specific instructions. That's just insane. If that happens, deal with the people who wrote or sold the assembler harshly.

I've seen about 20 or 30 cases where we actually had to code in assembly. This only happens extremely rarely, for bizarre performance optimizations (like having to use vector instructions that the optimizer doesn't want to use, because we know better), or for using atomic instruction primitives. Even for those, we usually had compiler macros.

I have no idea whether and how instruction execution in binary (not assembly) would be taught. It may happen in EE classes, as part of processor design (which is typically a VHDL/Verilog class). It may happen for a few homework problems in a computer architecture class. Even then, it will probably not use a real-world instruction set (those are way too complex for teaching), but an old or hypothetical instruction set (like IBM 360, Intel 808x or Z80, or MIX/MMIX). In the 1980s, as part of the "operating systems" class, I had to do one or two homework problems in binary IBM 360 and Cyber 6xxx instructions, and a half dozen in IBM 360 assembly.

And if ninja_root asks another repetitive and inane question, I'll get seriously upset at him.


Maelstorm

Well-Known Member

Reaction score: 132
Messages: 326

Yeah, I took a computer architecture course, and the advanced one as well. In our semester project, we had to develop a 16-bit RISC CPU that was pipelined. The class is long over with, so I'll attach the SVG file for the block diagram....or not since the forum does not allow SVG extension files... But yeah, binary coding was something to see because of the signals.


Attachments

OP
OP
D

Deleted member 53988

Guest


To end this topic:

Currently there are octal coding and decimal coding?


Crivens

Moderator
Staff member
Moderator

Reaction score: 887
Messages: 1,841

No. Those are encodings. Babylonians used base 6, if my memory serves me right. You may use any base you want, but the computer uses base 2. Only intel uses 1.95 internally in the pentium fpu and p4 pipeline.


Maelstorm

Well-Known Member

Reaction score: 132
Messages: 326

Consider this: Any and all programs that a computer runs and data that a computer processes is in binary because a computer cannot use anything else. So, anything that can get onto a computer must be in binary format or the computer cannot make sense of it. Even on modern computers that have temperature and voltage readings (which are analog quantities) must be converted to digital (binary) format before the computer can understand it. The characters in this post are all numbers. If ASCII is used, then A = 65. It's how computers work. Everything is a binary number. No exceptions. Since humans don't deal with binary too well, the programs on the computer converts the binary data into a format that humans can easily read. I have written some of the software that does that. You mentioned octal. Octal is an old binary type format were the bits are arranged into groups of three. So you have the following if you use 421 binary:

Code:
000        0
001        1
010        2
011        3
100        4
101        5
110        6
111        7
Hexadecimal is basically the same thing as octal with grouping of 4 bits (a nibble) instead of three so the coding is 8421 binary:

Code:
0000        0        1000        8
0001        1        1001        9
0010        2        1010        A (10)
0011        3        1011        B (11)
0100        4        1100        C (12)
0101        5        1101        D (13)
0110        6        1110        E (14)
0111        7        1111        F (15)
For decimal, you basically add up the position values where there's a 1 bit and that's the number. So 1010 has 1s in bit positions 2 and 4 which correspond to the values of 2 and 8, so 2 + 8 = 10 which is A in hex.


Note: Analog signals are continuously varying voltages/currents. Digital is fixed at either Vcc or Gnd which is voltage or no voltage with respect to ground. Devices known as ADCs (Analog to Digital Converters) convert a continuously varying analog signal into a digital number of so many bits. A 12-bit ADC has 4096 steps between 0 and whatever Vcc is. So when the input voltage is close to a step, the ADC reports the number that is associated with that step.


ralphbsz

Daemon

Reaction score: 1,123
Messages: 1,782

No. Those are encodings. Babylonians used base 6, if my memory serves me right. You may use any base you want, but the computer uses base 2. Only intel uses 1.95 internally in the pentium fpu and p4 pipeline.
At times like this, it would be good if the forum allowed to not just "like" a post by giving it a thumbs-up, but also give a laughing smiley to a post.

On a serious note: A former colleague of mine was advocating that computers should stop working in binary, and instead use trinary (each bit can store or process the values 0, 1 and 2). From a hardware point of view, this is doable, but extremely hard: every capacitor (memory cell) and transistor (gate, switch) would need to handle three voltages; but flash has demonstrated that it can be done, although the circuit elements would become a little larger. His argument was, however, not about electrical and space efficiency, but purely theoretical, and involves computer arithmetic: In number theory, there are lots of theorems that are true for odd primes (3, 5, 7, ...), and using one of those as the base of the number system would allow a lot of cross-checking and correctness proving in the arithmetic operations. Sadly, he is a former colleague, because he lost his two battles with cancer. Fortunately, he had a pleasant life (with friends, wine, ...) until near the end.


Crivens

Moderator
Staff member
Moderator

Reaction score: 887
Messages: 1,841

ralphbsz
Did you know that this fdiv thing was completely pointless? It was done to shrink the die and increase yield, but failed because the die area was set by the IO drivers on the border. The US outer border would not change if somehow some aliens stole nevada, for example. So no gain and a PR disaster.

When you are around here again let me know so I can invite you to a nice brew or so.


itsthosestonesman

Member

Reaction score: 22
Messages: 67

|I'll try to answer your original question, it can be tough getting to grips with all the concepts involved in this. I can give you a real example of "binary programming" from something I have worked on. Intel CPUs have some special instructions called streaming multimedia instructions, which are high performance instructions for processing data in memory. But the time I did the work these instructions were not supported by the C compiler I was using, which was gcc. That being the case, the only way to get the cpu to run those instructions was to code them as direct binary data in the source of my program. Let's have a bit of background to explain what I mean. When you write some source code in any native compiled language, that is, code that executes directly on the machines CPU, such as assembly language or C, the compiler will translate the source code of your program into a binary object code that the CPU is able to process. For example, let's say you have written in C "int b = 12"; the equivalent in assembly might be something like "mov eax, 12". In fact, when your C code is compiled, it is usually translated into assembly first, before being translated to binary. When the assembly is itself translated, the output is no longer readable as text, but is a sequence of binary byte values. These values encode the assembly instruction in a sequence that the CPU instruction decoder is able to understand to actually execute the instructions. Let's have an example. Here is a tiny program written in C source code:-
Code:
#include <stdio.h>
int main(int argc, char *argv[]) {
    int b = 5;
    b = b * 2;
    printf("value of b is %d\n", b);
}
You can compile this and run it as follows:-
Code:
$ cc -o t t.c
./t
value of b is 10
So far so good, we wrote a little program and ran it. We can also ask the compiler to output the assembly language it generated during compilation, which is a step that you don't normally bother to look at. To do this compile the source program again but this time using the -S option, as follows:-
Code:
$ cc -S t.c
That step creates a file called t.s, which contains the assembly language source code generated from compiling your C source code. This is still not in a form that the cpu can run, but it is getting closer. It is still human-readable and is still a type of source code, called assembly language. Let's have a look at t.s:-
Code:
$ cat t.s
        .text
        .file   "t.c"
        .globl  main                    # -- Begin function main
        .p2align        4, 0x90
        .type   main,@function
main:                                   # @main
        .cfi_startproc
# %bb.0:
        pushq   %rbp
        .cfi_def_cfa_offset 16
        .cfi_offset %rbp, -16
        movq    %rsp, %rbp
        .cfi_def_cfa_register %rbp
        subq    $32, %rsp
        movabsq $.L.str, %rax
        movl    %edi, -4(%rbp)
        movq    %rsi, -16(%rbp)
        movl    $5, -20(%rbp)
        movl    -20(%rbp), %edi
        shll    $1, %edi
        movl    %edi, -20(%rbp)
        movl    -20(%rbp), %esi
        movq    %rax, %rdi
        movb    $0, %al
        callq   printf
        xorl    %esi, %esi
        movl    %eax, -24(%rbp)         # 4-byte Spill
        movl    %esi, %eax
        addq    $32, %rsp
        popq    %rbp
        retq
.Lfunc_end0:
        .size   main, .Lfunc_end0-main
        .cfi_endproc
                                        # -- End function
        .type   .L.str,@object          # @.str
        .section        .rodata.str1.1,"aMS",@progbits,1
.L.str:
        .asciz  "value of b is [%d]\n"
        .size   .L.str, 20
        .ident  "FreeBSD clang version 6.0.1 (tags/RELEASE_601/final 335540) (based on LLVM 6.0.1)"
        .section        ".note.GNU-stack","",@progbits
Crikey! Now you can see why we prefer to write the original program in C or another high-level language. Just imagine if you had to type all that in just to write a simple program to double a constant. I won't go into how this works in detail but you can assume that somewhere in there are instructions to make a variable, assign the value 5 to it, then double it, then call the printf() function to write the value to standard output. In fact we can see the line that is equivalent to the assignment in "int b=5"; it is the assembly line "movl $5, -20(%rbp)"; and if you dig your way through it you might get an idea of which parts of the assembley code roughly correspond to the rest of the C source code.
But we still haven't got to binary code yet. To do that we must invoke the assember stage of the compiler, which is done by using the -c option to the cc command. This stage of compilation will translate the C to assembly, and then translate the assembly language and convert it to something called object code, which is the binary equivalent.
Code:
$ cc -c t.c
After running this it will be found that a file called t.o has been created, which is known as object code. And finally this file does contain the binary version of the instructions that were in the assembly file, which in turn were generated from the original C source code. And we can look at the contents of the t.o file using a binary file viewer such as the hexdump program, as follows:-
Code:
$ hexdump t.o
0000000 457f 464c 0102 0901 0000 0000 0000 0000
0000010 0001 003e 0001 0000 0000 0000 0000 0000
0000020 0000 0000 0000 0000 0268 0000 0000 0000
0000030 0000 0000 0040 0000 0000 0040 000a 0001
0000040 4855 e589 8348 20ec b848 0000 0000 0000
0000050 0000 7d89 48fc 7589 c7f0 ec45 0005 0000
0000060 7d8b c1ec 01e7 7d89 8bec ec75 8948 b0c7
0000070 e800 0000 0000 f631 4589 89e8 48f0 c483
0000080 5d20 76c3 6c61 6575 6f20 2066 2062 7369
0000090 5b20 6425 0a5d 0000 7246 6565 5342 2044
00000a0 6c63 6e61 2067 6576 7372 6f69 206e 2e36
00000b0 2e30 2031 7428 6761 2f73 4552 454c 5341
00000c0 5f45 3036 2f31 6966 616e 206c 3333 3535
00000d0 3034 2029 6228 7361 6465 6f20 206e 4c4c
00000e0 4d56 3620 302e 312e 0029 0000 0000 0000
00000f0 0014 0000 0000 0000 7a01 0052 7801 0110
.... (truncated for brevity)
Now finally we can see the binary data that was created by the assembly pass. This is no longer in a form that you can read or understand, but it does make perfect sense to the CPU when it comes to execute it. Somewhere in this binary data is a series of bytes that represents our original assembly code that was in turn generated from C code; and this series of binary data will be executed by the CPU. Believe it or not there is one further stage that must be performed before this file can actually be loaded and run by the operating system, which is called linkage. This step combines our small object file with system library files so that the printf() function and certain other essential functions can be accessed. I have only skimmed over the surface of the whole process here, but hopefully you get the rough idea.
So what exactly is the binary data that is in the object file? It consists of a series of instructions called opcodes, and their parameters. In the example given the assembly word "mov" is the assembly code representation of one type of opcode, and that will always generate a specific binary value to represent the "mov" (move) instruction to the CPU. The entire set of opcodes understood by a cpu is called the instruction set. If you rummage around the intel website at some time you will find that you can download books that describe the entire instruction set that a particular processor supports; for example, you will find one book that describes the "Intel 80386 instruction set", one for the pentium, etc.
Now, if you had a binary editor, you could actually write the object file directly by writing the values from the hexdump into a file, which would be another way to write the instructions for the cpu; actual binary programming; of course this would be far too laborious to ever do in practice, and you would have to look up every opcode in the instruction set book, work out what its parameters are, and write the correct sequence into the file. It would be almost impossible for a human to get it right and would be extremely time-consuming.
So when might we ever encounter a need to program in binary? As processors become more complex over the years, additional instructions are added to the instruction set, while the earlier instructions are retained for backwards compatibility. And sometimes instructions are added to a processor but are not added to the compiler or assembler by the programmers who develop the tools; the reason might be a lack of time, or the instructions are very rarely used, or any number of other factors. In those circumstances if you want to use the instructions that the compiler does not support, your only option is to write them directly as binary data into your source code, and both the assembler and C compiler provide a special syntax to allow you to do that. Going back to my original example of the steaming multimedia instructions, the version of gcc I was using at the time did not support them, so there was no way to access those instructions from C or assembly source code. However it is possible to embed snippets of assembler within C code, using something called "inline assembly language", and within one of those snippets it is possible to hard-code binary values that are to be executed directly by the CPU. In this was it was possible to write some code that used the streaming multimedia instructions, despite them not being available on the CPU. There is one other time that you might need to do "binary programming", which is when you have an executable program that you don't have the source code for; imagine you have shipped this program to lots of customers who have started reporting a bug to you. But the guy who wrote the program has left the company and you have lost the source code. Believe it or not this does happen in the real world. So you get your team to debug the program using something called a disassembler, which converts the binary back to assembly language, and you find the bug, and you work out how to fix it; but how do you give this fix to all your customers? You can use something called a binary patch, which which will edit the binary code of the executable file in situ on the customers system. If you ever have to do this you are getting in deep ;-) But that's another example of real-world "binary programming". Don't worry, your university will never mention that!
So back to your original question about whether a university course would cover this. I would expect a good university course to explain the concepts of computer architecture, cpu opcodes and instruction sets, how the CPU works in terms of binary instruction decode, and assembly language programming; with practical programming sessions most likely using a simple example cpu like a Z80 or 6800 to develop your knowledge. As with everything, working through real problems is far more valuable than just learning principles from a book. If you are lucky they will have actual hardware kits, such a Z80 development system, that will allow you to practice this and do exercises. Perhaps this is more likely to be encountered in an electronics or embedded systems course rather than in computer science, but even a computer science degree should cover some of this stuff in the first year, IMHO. Of course in the real world you will almost never do "binary programming" except under the rare kinds of circumstances I have described. But it's worth having a strong grip on how computers really work, when you come to work on higher level projects. Anyway hopefully that's give you a few ideas, feel free to ask questions if you like.


itsthosestonesman

Member

Reaction score: 22
Messages: 67

Correction - the line "In this was it was possible to write some code that used the streaming multimedia instructions, despite them not being available on the CPU." should say "In this was it was possible to write some code that used the streaming multimedia instructions, despite them not being available in the compiler".


itsthosestonesman

Member

Reaction score: 22
Messages: 67

I've thought of one more fairly specialised case where you might encounter binary programming. Certain processors can contain 'unofficial' undocumented opcodes, which programmers discover over the course of time; and these undocumented opcodes sometimes allow operations to be performed much more rapidly than the official documented opcodes. In this case embedded hard-coded values would be used to access the undocumented opcodes. This applies to things like highly optimised game engines running on consoles. The Z80 processor I mentioned earlier had some well-known undocumented opcodes that were widely used in early games written in assembly language. Similarly the Intel 80286 had an undocumented opcode that could be used to switch back from protected mode to real mode, which the book said was an illegal operation but was actually used in some software to access memory above the 1MB barrier. Of course we're going back in time now, however you can bet your bottom dollar that the current generation of processors also contain undocumented opcodes.


ShelLuser

Son of Beastie

Reaction score: 1,718
Messages: 3,537

Well, since the thread got necro'd I guess I might as well....

In some other universities still there are even binary coding lessons?
When I went to collage (last century) I actually learned to code in assembly and it's actually not too bad, especially in comparison to all the tools you currently have which can make coding a lot easier.

Of course I hardly used it (also because I'm not a full time programmer), but it's still useful to know about this aspect and I also believe it can definitely help to get a better understanding of the logic and theory behind coding.

|I'll try to answer your original question, it can be tough getting to grips with all the concepts involved in this.
Just wondering... you do realize that you're responding to a thread which is almost a year old, right? ;)


ralphbsz

Daemon

Reaction score: 1,123
Messages: 1,782

Following up on itsthestones' post ...

About 25 years ago, we were using lowly x86 instruction set machines (probably Pentium Pro) to do image processing. The problem was that our image processing code was very complex; we were doing double differences between three images, while simultaneously running each image through a correction based on mean/variance segmentation per pixel. This required keeping about 6 or 7 two-dimensional arrays (images or lookup tables) in memory at the same time. The problem was that we were writing the code in C++, and the function would get the addresses of these arrays as arguments (pointers). Those pointers had to be stored in registers, but the registers were also needed to do the actual arithmetic; remember the 32-bit x86 architecture has very few registers. So what happens was that the compiler ended up having to spill/reload the registered to/from memory all the time, which made the code run REALLY slow.

So with a group of a few people, we did the following. We coded a version of the C++ code that had the arrays at fixed memory locations. At this point, the addresses of the arrays were no longer in registers, but as constants in the instruction stream, which was very efficient to read and process. We suddenly had a lot of registers free, and were able to code it in such a fashion that some registers contained offsets into the arrays, and we used constant-relative addressing modes to access the images. This code ran really fast.

Great, but not practical: In the real world, the images and arrays are in variable places, and we need to pass pointers to the routine. But we can't keep the pointers in registers, and accessing them in memory is too slow, they need to be in the instruction stream.

So here is what we did. We ran the fast version of the code through the compiler with assembly output, and wrote an awk script that collected the instruction bytes in an array, which was stored in the source code. Then, when the function needed to be called, we would patch the array of bytes with the correct addresses for this call, and then call the modified array (yes, you can call an array of bytes as if it were a function, by using some nasty casts). This gave us our cake (fast execution) and eat it too (for images anywhere in memory). The piece of code that patched up the code (in the array) and then called it was named "izmel", which is the special sharp knife used for circumcisions.

This is the only major (more than a line or two) of assembly programming I've done in the last 25 years. And it wasn't really assembly programming: we let the C++ compiler write the assembly source for us, and then in a nutshell implemented our own relocating linker. Occasionally, we need to use an instruction or two; typically for atomicity (lock-free data structures, often using a CAS instruction), or to call vector or multimedia instructions.


Crivens

Moderator
Staff member
Moderator

Reaction score: 887
Messages: 1,841

Just wondering... you do realize that you're responding to a thread which is almost a year old, right? ;)
And which was started by a notorious troll.
The only reason it is still around is that it contains good nuggets.

ralphbsz
This is true evil and the lords of clean programming are frowning at you. But they are annoyed by the gods of speed and getting things done who clap and shout praise at you.


itsthosestonesman

Member

Reaction score: 22
Messages: 67

Well, since the thread got necro'd I guess I might as well....


When I went to collage (last century) I actually learned to code in assembly and it's actually not too bad, especially in comparison to all the tools you currently have which can make coding a lot easier.

Of course I hardly used it (also because I'm not a full time programmer), but it's still useful to know about this aspect and I also believe it can definitely help to get a better understanding of the logic and theory behind coding.


Just wondering... you do realize that you're responding to a thread which is almost a year old, right? ;)
oh maaan... I typed that while I was having a crap.... seemed a good idea at the time but now :'‑(


itsthosestonesman

Member

Reaction score: 22
Messages: 67

Following up on itsthestones' post ...

About 25 years ago, we were using lowly x86 instruction set machines (probably Pentium Pro) to do image processing. The problem was that our image processing code was very complex; we were doing double differences between three images, while simultaneously running each image through a correction based on mean/variance segmentation per pixel. This required keeping about 6 or 7 two-dimensional arrays (images or lookup tables) in memory at the same time. The problem was that we were writing the code in C++, and the function would get the addresses of these arrays as arguments (pointers). Those pointers had to be stored in registers, but the registers were also needed to do the actual arithmetic; remember the 32-bit x86 architecture has very few registers. So what happens was that the compiler ended up having to spill/reload the registered to/from memory all the time, which made the code run REALLY slow.

So with a group of a few people, we did the following. We coded a version of the C++ code that had the arrays at fixed memory locations. At this point, the addresses of the arrays were no longer in registers, but as constants in the instruction stream, which was very efficient to read and process. We suddenly had a lot of registers free, and were able to code it in such a fashion that some registers contained offsets into the arrays, and we used constant-relative addressing modes to access the images. This code ran really fast.

Great, but not practical: In the real world, the images and arrays are in variable places, and we need to pass pointers to the routine. But we can't keep the pointers in registers, and accessing them in memory is too slow, they need to be in the instruction stream.

So here is what we did. We ran the fast version of the code through the compiler with assembly output, and wrote an awk script that collected the instruction bytes in an array, which was stored in the source code. Then, when the function needed to be called, we would patch the array of bytes with the correct addresses for this call, and then call the modified array (yes, you can call an array of bytes as if it were a function, by using some nasty casts). This gave us our cake (fast execution) and eat it too (for images anywhere in memory). The piece of code that patched up the code (in the array) and then called it was named "izmel", which is the special sharp knife used for circumcisions.

This is the only major (more than a line or two) of assembly programming I've done in the last 25 years. And it wasn't really assembly programming: we let the C++ compiler write the assembly source for us, and then in a nutshell implemented our own relocating linker. Occasionally, we need to use an instruction or two; typically for atomicity (lock-free data structures, often using a CAS instruction), or to call vector or multimedia instructions.
Your solution sounds great! You've reminded me, implementing things like memory barriers for lockless is another place I've used very small amounts of inline asm in the last ten years... and writing things like a fast spinlock in asm to avoid the humungous overhead of using pthreads. By co-incidence I also worked on image processing (satellite images) many years ago, back then I was using masm to write some filter routines, convolution etc, trying to squeeze performance out of a 386... hahaha, those were the days :)


itsthosestonesman

Member

Reaction score: 22
Messages: 67

Your solution sounds great! You've reminded me, implementing things like memory barriers for lockless is another place I've used very small amounts of inline asm in the last ten years... and writing things like a fast spinlock in asm to avoid the humungous overhead of using pthreads. By co-incidence I also worked on image processing (satellite images) many years ago, back then I was using masm to write some filter routines, convolution etc, trying to squeeze performance out of a 386... hahaha, those were the days :)
For anyone else reading this who is interested in low-level cpu design and how computers work under the covers, this https://gigatron.io/ looks like a really nice project to have a play with. I wish tandy's were still around with the heathkit kits, but they appear to have vanished. Making a cpu from TTL is a great idea. Or you could go for a nice Z80 trainer like this http://www.kswichit.com/Z80/Z80.html. I don't have any connection with either of these sites, I'm sure there are others. Of course they won't run your favourite o/s but it's nice to know that some people are still making kit like this.


Nicola Mingotti

Well-Known Member

Reaction score: 160
Messages: 413

However Herbert Schildt is true, that in 99.999999% real world stuff binary code /assembly is not use
my $0.000005 on this discussion. by choice an impossible value:)

*) it is quite apparent that that percent value is purely psychological, not as a statistical estimation. So, take from it what it can give.

*) if you interpret as, "it is true that a tiny fraction of all software lines written is in assembly today ?" That is probably true. Just think how many web developer are out there !

*) if you interpret as "it is true that in the very large majority of computer application bought by US do not contain assembly?" then the aswer is probably yes. Consider for example phone dev, mostly you write in Java (android case) you don’t have access to the metal. other example, again, Web dev, the other huge player today, forget assembly at all.

*) But now, see the thing from another angle, every device, every phone has something wrtten in assembly in it with good probability ! Assembly in embedded is far from forgotten.
usually you don t buy assembly software because it comes by default when you buy the machine. How many driver contain assembly? I don’t know, but i suppose many do.


itsthosestonesman

Member

Reaction score: 22
Messages: 67

my $0.000005 on this discussion. by choice an impossible value:)

*) it is quite apparent that that percent value is purely psychological, not as a statistical estimation. So, take from it what it can give.

*) if you interpret as, "it is true that a tiny fraction of all software lines written is in assembly today ?" That is probably true. Just think how many web developer are out there !

*) if you interpret as "it is true that in the very large majority of computer application bought by US do not contain assembly?" then the aswer is probably yes. Consider for example phone dev, mostly you write in Java (android case) you don’t have access to the metal. other example, again, Web dev, the other huge player today, forget assembly at all.

*) But now, see the thing from another angle, every device, every phone has something wrtten in assembly in it with good probability ! Assembly in embedded is far from forgotten.
usually you don t buy assembly software because it comes by default when you buy the machine. How many driver contain assembly? I don’t know, but i suppose many do.
Perhaps around ten years ago, the technical lead of the Sony games development lab in the uk (hopefully they are still in business here) came and gave us a talk on how they develop software for consoles. He said the model is completely different from the PC world where more efficient hardware comes out every year. In console land they keep the hardware constant and unchanged, for perhaps ten years, and instead evolve the programming techniques used to squeeze performance out of the same hardware (I think at the time it was PS/2). So to produce more advanced games as time went on and keep customers buying, he said they used a lot of assembly language and learned how to program the hardware inside-out, working out how to get the maximum performance from the chips in the box. If console games are still developed that way, that might be one area that still makes extensive user of assembly language. The business model was to maximise the ROI on the initial development of the custom chips in the console by shipping millions of them and amortizing the cost over a long period. Anyway I found this an interestingly different perspective on a computer business, compared to what we are used to, getting ever more powerful hardware each year and focusing on minimising the cost of writing new software.
