Greetings.
I am trying to make a guest VM work with wifi connection.
Nothing too fancy: alpine vm in bhyve, and use wifi to connect to the outside world.
It worked just fine with
I tried to create a "switch" in vm-bhyve with
Then I try to
I believe that would be an extremely simple thing to do and for sure many people did it successfully. I couldn't find the exact threads though. Most of them deal with much more sophisticated configurations than the one that I am looking to use.
Maybe the culprit is the quirks of the wifi driver, or some bugged defaults in vm-bhyve.
I wish I could take away from it some acquired knowledge to be able to debug such things in future.
Thanks in advance.
Here's some useful outputs:
I am trying to make a guest VM work with wifi connection.
Nothing too fancy: alpine vm in bhyve, and use wifi to connect to the outside world.
It worked just fine with
eth0
connection (meaning connecting to the world using an ethernet cable) but when switching to wlan0
something breaks though. I tried to create a "switch" in vm-bhyve with
wlan0
as the physical device, and also tried to create a custom manually configured bridge (though it seems I did pretty much the same thing as the vm-bhyve switch does: ifconfig bridge0 addm wlan0 addm tap0
). Then I try to
udhcpc
in alpine to recieve IP. On the host side I see dhcp requests coming from alpine and getting no response. I believe that would be an extremely simple thing to do and for sure many people did it successfully. I couldn't find the exact threads though. Most of them deal with much more sophisticated configurations than the one that I am looking to use.
Maybe the culprit is the quirks of the wifi driver, or some bugged defaults in vm-bhyve.
I wish I could take away from it some acquired knowledge to be able to debug such things in future.
Thanks in advance.
Here's some useful outputs:
Code:
vm switch info public
local: _netgraph,: bad variable name
------------------------
Virtual Switch: public
------------------------
type: standard
ident: vm-public
vlan: -
physical-ports: wlan0
bytes-in: 853886 (833.873K)
bytes-out: 1411870 (1.346M)
virtual-port
device: tap0
vm: alpine
Code:
ifconfig
em0: flags=8863<UP,BROADCAST,RUNNING,SIMPLEX,MULTICAST> metric 0 mtu 1500
options=481249b<RXCSUM,TXCSUM,VLAN_MTU,VLAN_HWTAGGING,VLAN_HWCSUM,LRO,WOL_MAGIC,VLAN_HWFILTER,NOMAP>
ether e4:b9:7a:42:10:ae
media: Ethernet autoselect
status: no carrier
nd6 options=29<PERFORMNUD,IFDISABLED,AUTO_LINKLOCAL>
lo0: flags=8049<UP,LOOPBACK,RUNNING,MULTICAST> metric 0 mtu 16384
options=680003<RXCSUM,TXCSUM,LINKSTATE,RXCSUM_IPV6,TXCSUM_IPV6>
inet6 ::1 prefixlen 128
inet6 fe80::1%lo0 prefixlen 64 scopeid 0x2
inet 127.0.0.1 netmask 0xff000000
groups: lo
nd6 options=21<PERFORMNUD,AUTO_LINKLOCAL>
bridge0: flags=8802<BROADCAST,SIMPLEX,MULTICAST> metric 0 mtu 1500
ether 58:9c:fc:10:bd:73
id 00:00:00:00:00:00 priority 32768 hellotime 2 fwddelay 15
maxage 20 holdcnt 6 proto rstp maxaddr 2000 timeout 1200
root id 00:00:00:00:00:00 priority 32768 ifcost 0 port 0
groups: bridge vm-switch viid-b36eb@
nd6 options=9<PERFORMNUD,IFDISABLED>
wlan0: flags=8943<UP,BROADCAST,RUNNING,PROMISC,SIMPLEX,MULTICAST> metric 0 mtu 1500
ether dc:8b:28:62:f2:64
inet 172.21.11.175 netmask 0xfffff800 broadcast 172.21.15.255
groups: wlan
ssid "SSID" channel 6 (2437 MHz 11g) bssid e4:38:83:6f:03:04
regdomain FCC country US authmode WPA2/802.11i privacy ON
deftxkey UNDEF AES-CCM 2:128-bit powersavemode CAM powersavesleep 100
txpower 30 bmiss 10 scanvalid 60 protmode CTS wme roaming MANUAL
parent interface: iwm0
media: IEEE 802.11 Wireless Ethernet DS/2Mbps mode 11g
status: associated
nd6 options=29<PERFORMNUD,IFDISABLED,AUTO_LINKLOCAL>
vm-public: flags=8843<UP,BROADCAST,RUNNING,SIMPLEX,MULTICAST> metric 0 mtu 1500
ether a6:b1:10:49:47:f5
id 00:00:00:00:00:00 priority 32768 hellotime 2 fwddelay 15
maxage 20 holdcnt 6 proto rstp maxaddr 2000 timeout 1200
root id 00:00:00:00:00:00 priority 32768 ifcost 0 port 0
member: tap0 flags=143<LEARNING,DISCOVER,AUTOEDGE,AUTOPTP>
ifmaxaddr 0 port 5 priority 128 path cost 2000000
member: wlan0 flags=143<LEARNING,DISCOVER,AUTOEDGE,AUTOPTP>
ifmaxaddr 0 port 3 priority 128 path cost 370370
groups: bridge vm-switch viid-4c918@
nd6 options=9<PERFORMNUD,IFDISABLED>
tap0: flags=8943<UP,BROADCAST,RUNNING,PROMISC,SIMPLEX,MULTICAST> metric 0 mtu 1500
description: vmnet/alpine/0/public
options=80000<LINKSTATE>
ether 58:9c:fc:10:ff:ff
groups: tap vm-port
media: Ethernet autoselect
status: active
nd6 options=29<PERFORMNUD,IFDISABLED,AUTO_LINKLOCAL>
Opened by PID 6717
Code:
12:23:20.206415 IP (tos 0x0, ttl 64, id 0, offset 0, flags [none], proto UDP (17), length 328)
0.0.0.0.bootpc > 255.255.255.255.bootps: [udp sum ok] BOOTP/DHCP, Request from 58:9c:fc:04:8c:63 (oui Unknown), length 300, xid 0x25ae424d, secs 1766, Flags [none] (0x0000)
Client-Ethernet-Address 58:9c:fc:04:8c:63 (oui Unknown)
Vendor-rfc1048 Extensions
Magic Cookie 0x63825363
DHCP-Message Option 53, length 1: Discover
MSZ Option 57, length 2: 576
Parameter-Request Option 55, length 7:
Subnet-Mask, Default-Gateway, Domain-Name-Server, Hostname
Domain-Name, BR, NTP
Vendor-Class Option 60, length 12: "udhcp 1.36.1"
Client-ID Option 61, length 7: ether 58:9c:fc:04:8c:63
