Schedule driven GPIO events

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

I want to use GPIO outputs to drive an IOT Power Strip.

My question is about triggering scheduled events.
For instance I want to issue a GPIO command to turn a pin on and off on a schedule.

So I could use cron but would like to avoid system utilities.
Looking around I found sysutils/fcron and sysutils/anacron. Both can run commands on a schedule.
anacron seems to use daily jobs. I need minute precision.

Another option I have considered is deskutils/calcurse.
I like the approach of scheduling by calendar. It can run commands too.

Can you recommend any programs I may have missed.

I need to schedule a command like gpioctl to run 4 times a day.


obsigna

Daemon

Reaction score: 859
Messages: 1,253

Even, if I don't exactly understand, what is wrong with a cronjob -- I got a lot of it in my crontabs --, the most effective solution would be, to write your own daemon (see here: https://forums.freebsd.org/threads/polling-a-sysctl-value.63501), wich you would modify to do a sleep(3) for the required amount of seconds (21600 s), and then calls the respective gpio(3) instruction.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

Here is a sample task I need to do. I have a Siemans PLC at work that is old and getting flaky.
It keeps bad time and cannot handle DST time changes. I have to mess with it too much.

Surly I could find some timer circuit for less $ but I like to have an SSH window into the controller.
Plus I could feed cameras through it for auxiliary function.

This PLC controls a solenoid for Air Powered Horn that sounds at the beginning and end of the workday.
I would like to replace it with something else. Like a old Pi or anything with FreeBSD GPIO.

So I need to accurately trigger a solenoid 4 times a day.

I was looking at this program with interest. deskutils/remind/
This is overkill but I like the flexibility. Especially with complex scheduling.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

the most effective solution would be, to write your own daemon
Thank You for mentioning that. In the end that is going to be the best solution.
But I think I want a daemon for each pin. A GPIO service for each pin. Totally independent.
Then I could make one GPIO pin service dependent on the state of another.

I really see the need the for an event driven GPIO program.
Cron is not preferable to me.

Anybody ever hear of Light-O-Rama?
They make Christmas Light Controllers. Mega tree. RS485 connects to the various junction boxes.
It is bad ass. Why is there no software for more 'General" I/O events?

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

I am looking at the deskutils/calcurse codebase.
If I changed 'Appointments' into 'Events' it might fit the bill.
Not Light-O-Rama but basic scheduled on off events.
Lots of un-needed features though..


mer

Well-Known Member

Reaction score: 191
Messages: 333

But I think I want a daemon for each pin. A GPIO service for each pin. Totally independent.
Then I could make one GPIO pin service dependent on the state of another.
Take a look at the way moused and some other things work with hot pluggable devices.
You write a script once, then you have a symlink like moused.ums0 that the script looks at it's name to figure out what "port" (pin) it needs to work on.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

With regards to calcurses, The notfcation system is not very robust. So that is a bust.
This guy reverted to cron.

So I started playing with dialog --calendar but I really don't have the skills to build my pipe dream.
Was thinking of hooking the fcron scheduler into a curses calendar interface. Similar to calcurses.
I was hoping to adopt some existing code but that is looking futile.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

Well the best deals require patience.
I had patience as the seller took 10 days to ship my item.
He only shipped me one but I ordered 5.
It has been that kind of week.

Good news is I have the one IOT Relay working on my APU2.
Had to change type from Open Drain to Push Pull.
So finally I have outlet control.

Now its time to test out fcron. I will use a clock radio for testing.


astyle

Aspiring Daemon

Reaction score: 258
Messages: 583

If you can hook up your light controller to a FreeBSD machine and control that using command line first, there's theoretically no limit to how fancy you can get afterwards. But first things first, get the controller working under FreeBSD.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

I don't have a Light-O-Rama controller. I just marvel at the off the shelf approach. Nothing new there.
RS485 daisychained controllers. Outlet boxes and some nice orchestration software.
Just application of newer electronics like the triacs for RGB LED's for spectacular effect.

I have been studying my needs and messing with cron/fcron.
It seems to me what we are missing in FreeBSD is a gpiod. On Linux this is what is used.
I looked at the Linux gpiod code and the differences are too great to port.
Scheduling is handled with the daemon as well as monitoring.
There is a OpenBSD GPIO daemon implementation that is closer to our GPIO subsystem.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

fcron runs on seconds precision, and does cron and anacron.
So how are you doing this? f/a/cron all use the same time/date format?
Is it like this? Running a script?

I don't see second precision here:
Code:
root@APU2:~ # fcrondyn
fcrondyn> ls
ID   |USER     |SCHEDULE        |CMD
3    |root     |2021-06-27 12:11|/usr/sbin/gpioctl 0 1
2    |root     |2021-06-27 12:12|/usr/sbin/gpioctl 0 0


astyle

Aspiring Daemon

Reaction score: 258
Messages: 583

Sounds more like a Pi application - it may be better to have a dedicated device to run the light show for a few hours. FreeBSD or Rasbian, proper command line control, and then you can get as fancy as you want.

OP
Phishfry

Phishfry

Beastie's Twin

Reaction score: 2,575
Messages: 5,461

FreeBSD's crontab(5) does seem to support seconds in some capacity:
@every_second Run once a second.

fcron also has the ability to use seconds for repeats.

Neither of these seem to accommodate a start time/stop time in seconds like I want?


Alain De Vos

Daemon

Reaction score: 549
Messages: 1,898

E.g, one line out of my fcrontab
Code:
@first(2000s)  1800s  /usr/home/x/Root/bin/snap_usr_home_increment  -u root
It runs first 2000s after starting and following regularly at 1800s time intervals.
Note, when you write 2000 instead of 2000s it will interprete it as 2000 minutes.


astyle

Aspiring Daemon

Reaction score: 258
Messages: 583

FreeBSD's crontab(5) does seem to support seconds in some capacity:
@every_second Run once a second.

fcron also has the ability to use seconds for repeats.

Neither of these seem to accommodate a start time/stop time in seconds like I want?
In which case, it might be easier to daisy-chain a couple scripts... write a script whose total run time is an hour, and has a PID file. Then your crontab has to check for completion of the script before starting it up all over again. It shouldn't take that many processor cycles to do the checking.
